12.1 inch Touch Panel PC for RFID access control

12.1 inch Touch Screen Panel PC for RFID access control

12.1 inch TFT touch color screen, full interface display, all operations can be done directly on the touch screen
Integrated with high performace Intel J1900 processor, up to 2.42 GHz.
Dual 125KHz-EM or 13.56MHz-Mifare RFID reading capacity
Windows or Linux operating system support
IP65 Front panel watertight and dustproof is the perfect solution for harsh environments

As industrial Panel PC provider, announces the 12.1 inch RFID panel pc, an intelligent all-in-one access control terminal that reads both MIFARE and EM tags and also optional for NFC. The fanless panel PCs are built on the low power, low heat chipsets. The x86-based architecture is more flexible than traditional windows CE control terminals. The x86 architecture enables system developers to integrate sophisticated time attendance, access control and/or prepaid card software for door access, time attendance, ticketing, membership clubs, photocopying, dining, laundries or parking access control.

RFID Automated Parking Control System
This panel pc can be used to access and control a database and monitor the toll collection transaction history.

Access Control Door System
The two-in-one EM/MIFARE compliant RFID module installed in the panel pc supports sophisticated security applications.

Healthcare Solutions
The RFID Panel PC with RFID technology applied in hospitals and healthcare facilities can identify and track patients, objects, and assets, and can speed up or eliminate many manual operations in checking and processing patients.

The x86 all-in-one panel PC with Windows and Linux operating systems is easily integrated with data intensive applications such as voice recognition and face recognition software( camera optional).

The fanless panel PC have less downtime and extended operational lives as they are not susceptible to overheating problems caused by fan failures.

This is RFID Touch Computer systems combine IP 65 compliant front panels with CNC cutted shields to ensure the system is secured against vandalism and protected against extreme environmental conditions.

Information

Additional description
Model ID:
EB-121RA-OEM





O/S Linux  / Windows
CPU Intel® Celeron® Processor J1900 (2M Cache, up to 2.42 GHz)
Chipsets Intel® Bay Trail SOC
RAM 2GByte DDR3L-1600
Hard Drive 32GB SSD
Graphic Intel HD Graphics
Audio Realtek HD ALC 662  ,2*2W Loudspeaker
LAN Realtek RTL8111F , 1*10/100/1000MBit RJ45 Ports
External Ports HDMI
2*USB2.0
2*USB3.0
2* COM
1*RJ45
VGA
Line out
MIC
Power on/off
DC-in(12V)
Internal port  1*Sata 300MB/S (1*MSATA)
1*MiniPCI-E
Input Voltage 12V DC-in
Operating Temperature ,-10℃ to +60℃
RFID 125Khz  / ID card  (EM4100)
13.56Mhz  / IC card  (ISO14443A)
Driver Windows, Linux;
Display(mm) 261.12x163.2
Aspect Ratio 16:10
Physical Resolution 1280(W)*800(H)
Brightness 400
Contrast Ratio 800:1
React time 30 (Typ.)(Tr+Td) ms
Visual angle  80/80/65/80(L/R/U/D)
Touch Panel  (Optional)  4 wire Resistive touch panel
Touch Panel Driver Windows, Linux,
React time touch panel <10 ms
Surface Hardness ≥3 H( Resistive touch panel)
Cooling System Fanless
Front Panel IP65
Install VESA100x100  , Embedded  ,  Panel , Wall , Rack , Stand
Case Aluminum ,steel sheet
Size(WxHxD)(mm) 320x280x60
Optional W-lan optional
IP65 class
Bluetooth 2.0
Advanced RAM and SSD/HDD
Packing list:
1* CD Driver  ,  1* PC User Menu  ,  1* Power Adapter  ,  4* fastener  ,
